CUT  WHEELS AND PINIONS FOR

          ENGLISH STYLE BRACKET CLOCK REVISITED

by JOHN. W. PARSLOW

NOW WITH DATE WORK SUPPLEMENT

Wheels to be crossed out / Pinions supplied on stubs to be cut off and fitted to arbor  1/2/3 or 4 pinions on one stub  PHOTO



Some years ago Mr John Tyler of California published a book entitled " How to Make An English Style Bracket Clock ". This book described in great detail and with many photographs, the manufacture of a break-arch style bracket clock. In 1991 the book was republished , later a list of modifications were listed by a Dutch clock club.

A study of the book showed that Mr Tyler has a very well equipped workshop, My own equipment consists of a Myford Series Seven lathe equipped with a vertical slide and machining vice, a small drilling machine, a home made wheel cutting spindle and pinion milling fixture plus a range of hand tools possessed by the model engineer. It was clear that to produce this clock on my equipment and to include the modifications described by the Dutch clock club some modifications and simplification of Mr Tyler's design would be required.

Two versions of this clock will be described  i.e. a simple timepiece and a striking clock, due to my modifications these clocks use two less cutters than Mr Tyler's

Now with date work supplements

Cutters Module  0.6mod wheel , 0.55 x 8 leaf, 0.55 x 6 pinion

ALL PRICES PLUS POSTAGE & PACKING

  Back To Home Page
wheels and pinions are made to order

ITEM

      p

BOOK              28. 50
GOING TRAIN   Back To Clock Construction

Books

GREAT WHEEL 22. 50
CENTRE WHEEL 14. 50              ORDER FORM
THIRD WHEEL 14. 50
ESCAPE WHEEL 15. 50
HOUR WHEEL 14. 50
MINUTE & REVERSE MINUTE WHEELS / 2 14. 00
MAINTAINING RATCHET 20. 00
FUSEE RATCHET 12. 50
BARREL RATCHET 13. 00
STRIKE TRAIN
GREAT WHEEL 22. 50
PIN WHEEL 14. 50



PALLET WHEEL 14. 50
WARNING WHEEL 14. 50
FUSEE RATCHET 12. 50
BARREL RATCHET 13. 00
CENTRE, PIN & PALLET PINIONS / 3 x 8 LEAF "to cut off "  EN24T 30. 00 Photo by kind permission of

Mr J Parslow

CENTRE 8 LEAF PINION ON ARBOR STUB FOR TURNING 25. 00
PALLET WHEEL 8 LEAF PINION ON ARBOR STUB FOR TURNING 25. 00
PIN WHEEL 8 LEAF PINION ON ARBOR STUB FOR TURNING 25. 00
THIRD, ESCAPE, WARNING & FLY  PINIONS / 4 x 7 LEAF ON ONE ARBOR  "to cut off " EN24T 30. 00
SAME ON INDIVIDUAL ARBORS FOR TURNING EN24T 7 LEAF                 24. 00     EACH
CENTRE PINION 8 LEAF TIMEPIECE  "to cut off " EN24T 16. 00
THIRD & ESCAPE PINION 7 LEAF TIMEPIECE  " to cut off " EN24T 19. 50
MOTION PINION 12. 50
MAINSPRINGS X 2 P. O A.
SUSPENSION SPRING 4. 25
DIALS           Photo check photo link
3" CAST BRASS BELL     Photo 17. 50


Please see message from Mr Parslow below

Hello Ian.  An M.E reader has pointed out misprints in the M.E. series .

Page. 1. of the manual. The position of the  cutout on the front plate is shown out of position. The dimension of the cut out from the left hand side of the plate should be 1.700 and not 1.437 as shown  and the distance from the top of the plate should be 1.312 and not 1.562 as shown.

Page. 17  The distance for the motion work clutch on the centre arbor should be approximately 0.210" not 0.325" as shown.

Page. 24 of the manual. The dimension of the escape wheel arbor from the top of the plate should be 1.650

and not 1.875 as shown.

I have checked these later dimensions against my original hand drawings and the clock itself and can confirm that they are correct.

Will you kindly forward this E-mail to those who have already purchased the manual.

Regards.

 John Parslow.



Please verify prices before ordering as prices can fluctuate due to market forces
